上海凯泉泵业KQH/KQWH单级化工泵

第二代KQWH/KQH系列单级卧式/立式化工泵是我公司在原化工泵基础上，充分考虑到化工泵在使用过程中对结构要求的特殊性，汲取国内外先进结构经验，轴采用分轴式，特殊套轴式结构，具有结构简单、同心度高，振动小，使用可靠，维修方便等特点，是创新研发的新一代单级化工泵。

在线咨询全国热线
4001-077-588

产品概述：

口　　径：DN40～DN300mm
流　　量：4～1080m³/h
扬　　程：5～129m
配套功率：0.75～200kW

第二代KQWH/KQH系列单级卧式/立式化工泵是我公司在原化工泵基础上，充分考虑到化工泵在使用过程中对结构要求的特殊性，汲取国内外先进结构经验，轴采用分轴式，特殊套轴式结构，具有结构简单、同心度高，振动小，使用可靠，维修方便等特点，是创新研发的新一代单级化工泵。
优势特点：
1.该系列泵机泵轴分段设计，从根本上避免了腐蚀对电机轴的破坏；
2.可靠新颖的泵轴结构，卧式和立式泵可选用不同型号的标准电机驱动水泵；
3.泵轴和电机轴采用刚性连接，振动小、噪音低；
4.采用优秀的水力模型设计，泵的性能稳定，效率高；
5.重要零部件采用熔模精密铸造，尺寸精度高，流道光洁。

行业应用：

部分化工、油品输送和部分酸、碱、盐、空调、采暖、卫生用水、环保、水处理、冷却冷冻系统，液体循环和供水、增压及灌溉等领域中具有一定腐蚀性的冷水和热水输送。介质固体不溶物体积不超过单位体积0.1%，粒度<0.2mm类似于水的介质。

上海凯泉泵业KQH/KQWH单级化工泵参数表

序号	型号	额定流量 m³/h	额定扬程 m	效率	额定转速 rpm	叶轮外径	电机功率	出口口径	进口口径	电机重量
1	KQWH100-125(I)-II	100	5	73.81	1480	156	2.2	100	100	41.5
2	KQWH100-160(I)-II	100	8	79.18	1480	178	4	100	100	63.2
3	KQWH100-160(I)A-II	87	6.3	71.87	1480	156	3	100	100	46
4	KQWH100-200(I)-II	100	12.5	76.47	1480	216	5.5	100	100	71.2
5	KQWH100-200(I)A-II	86	9.3	72.69	1480	194	4	100	100	63.2
6	KQWH100-250(I)-II	100	20	78.36	1480	250	11	100	100	121
7	KQWH100-250(I)A-II	93	17.4	76.01	1480	235	7.5	100	100	85.1
8	KQWH100-250(I)B-II	87	15	76.07	1480	220	5.5	100	100	71.2
9	KQWH100-315(I)-II	100	32	82.67	1480	318	15	100	100	142
10	KQWH100-315(I)A-II	91	27	71.67	1480	296	11	100	100	121
11	KQWH100-315(I)B-II	79	20	71.02	1480	263	7.5	100	100	85.1
12	KQWH100-400(I)-II	100	50	66.94	1480	373	30	100	100	284
13	KQWH100-400(I)A-II	94	44	80.27	1480	358	22	100	100	209
14	KQWH100-400(I)B-II	87	38	69.54	1480	333	18.5	100	100	181
15	KQWH100-100-II	160	12.5	66.09	2960	128	11	80	100	113
16	KQWH100-100A-II	143	10	71.38	2960	122.5	7.5	80	100	69.2
17	KQWH100-125-II	160	20	78.58	2960	149.5	15	80	100	123
18	KQWH100-125A-II	143	16	73.09	2960	135.5	11	80	100	113
19	KQWH100-160-II	160	32	77.7	2960	180	22	80	100	182
20	KQWH100-160A-II	150	28	81.59	2960	170	18.5	80	100	142
21	KQWH100-160B-II	138	24	76.61	2960	160	15	80	100	123
22	KQWH100-200-II	160	50	79.9	2960	215	37	80	100	265
23	KQWH100-200A-II	150	44	75.49	2960	202	30	80	100	246
24	KQWH100-200B-II	138	37.5	74.42	2960	190	22	80	100	182
25	KQWH100-250-II	160	80	75.32	2960	257	55	80	100	413
26	KQWH100-250A-II	150	70	83.53	2960	238	45	80	100	323
27	KQWH100-250B-II	138	60	76.06	2960	225	37	80	100	265
28	KQWH100-315-II	160	125	65.39	2960	314	90	80	100	569
29	KQWH100-315A-II	150	110	71.83	2960	293	75	80	100	546
30	KQWH100-315B-II	143	100	70.89	2960	286	75	80	100	546
31	KQWH100-315C-II	134	88	68.02	2960	270	55	80	100	413
32	KQWH40-100-II	6.3	12.5	58	2960	102	0.75	32	40	18.1
33	KQWH40-100A-II	5.6	10	34.8	2960	96	0.75	32	40	18.1
34	KQWH40-125-II	6.3	20	58.55	2960	126	1.1	32	40	19.5
35	KQWH40-125A-II	5.6	16	52	2960	112	0.75	32	40	18.1
36	KQWH40-160-II	6.3	32	42.45	2960	155.6	2.2	32	40	27.1
37	KQWH40-160A-II	5.9	28	45.08	2960	146	1.5	32	40	23.3
38	KQWH40-160B-II	5.5	24	45.56	2960	135	1.1	32	40	19.5
39	KQWH40-200-II	6.3	50	36	2960	194	4	32	40	48.3
40	KQWH40-200A-II	5.9	44	36.6	2960	182	3	32	40	38.8
41	KQWH40-200B-II	5.3	36	33	2960	165	2.2	32	40	27.1
42	KQWH50-100-II	12.5	12.5	57.62	2960	108	1.1	32	50	19.5
43	KQWH50-100A-II	11	10	50.5	2960	100	0.75	32	50	18.1
44	KQWH50-125-II	12.5	20	58.72	2960	126	1.5	32	50	23.3
45	KQWH50-125A-II	11	16	57.53	2960	114	1.1	32	50	19.5
46	KQWH50-160-II	12.5	32	56.31	2960	153	3	32	50	38.8
47	KQWH50-160A-II	10	27	49.84	2960	144	2.2	32	50	27.1
48	KQWH50-160B-II	10.4	22	55.1	2960	132	1.5	32	50	23.3
49	KQWH50-200-II	12.5	50	47.87	2960	187	5.5	32	50	55.1
50	KQWH50-200A-II	11.7	44	49.64	2960	182	4	32	50	48.3
51	KQWH50-200B-II	10.4	36	47.9	2960	166	3	32	50	38.8
52	KQWH50-250-II	12.5	80	40.07	2960	235	11	32	50	113
53	KQWH50-250A-II	11.6	70	34.15	2960	230	7.5	32	50	69.2
54	KQWH50-250B-II	10.8	60	36.77	2960	221	7.5	32	50	69.2
55	KQWH65-100-II	25	12.5	66.53	2960	109	1.5	40	65	23.3
56	KQWH65-100A-II	22.3	10	59.86	2960	103	1.1	40	65	19.5
57	KQWH65-125-II	25	20	70.6	2960	125	3	40	65	38.8
58	KQWH65-125A-II	22.3	16	62.7	2960	113	2.2	40	65	27.1
59	KQWH65-160-II	25	32	75.17	2960	156	4	40	65	48.3
60	KQWH65-160A-II	23	28	54.37	2960	141	4	40	65	48.3
61	KQWH65-160B-II	20	24	70.44	2960	134	3	40	65	38.8
62	KQWH65-200-II	25	50	64.44	2960	196	7.5	40	65	69.2
63	KQWH65-200A-II	23.4	44	59.15	2960	180	7.5	40	65	69.2
64	KQWH65-200B-II	21.8	38	59.85	2960	168	5.5	40	65	55.1
65	KQWH65-250-II	25	80	55.18	2960	237	15	40	65	123
66	KQWH65-250A-II	23.4	70	45.05	2960	225	11	40	65	113
67	KQWH65-250B-II	21.6	60	52.2	2960	213	11	40	65	113
68	KQWH65-315-II	25	125	38.44	2960	293	30	40	65	246
69	KQWH65-315A-II	23.7	113	37.29	2960	288	22	40	65	182
70	KQWH65-315B-II	22.5	101	36.13	2960	273	18.5	40	65	142
71	KQWH65-315C-II	20.6	85	36.13	2960	258	15	40	65	123
72	KQWH65-100(I)-II	50	12.5	72.78	2960	119	3	65	65	38.8
73	KQWH65-100(I)A-II	44.7	10	73.23	2960	103	2.2	65	65	27.1
74	KQWH65-125(I)-II	50	20	79.61	2960	137	5.5	65	65	55.1
75	KQWH65-125(I)A-II	45	16	78.52	2960	125	4	65	65	48.3
76	KQWH65-160(I)-II	50	32	80.41	2960	168	7.5	50	65	69.2
77	KQWH65-160(I)A-II	46.7	28	77.93	2960	157	7.5	50	65	69.2
78	KQWH65-160(I)B-II	40	24	76.31	2960	144	5.5	50	65	55.1
79	KQWH65-200(I)-II	50	50	70.69	2960	193	15	50	65	123
80	KQWH65-200(I)A-II	47	44	75.01	2960	182	11	50	65	113
81	KQWH65-200(I)B-II	43.5	38	73.99	2960	171	7.5	50	65	69.2
82	KQWH65-250(I)-II	50	80	65.69	2960	240	22	50	65	182
83	KQWH65-250(I)A-II	46.7	70	70.82	2960	227	18.5	50	65	142
84	KQWH65-250(I)B-II	43.3	60	67.99	2960	211	15	50	65	123
85	KQWH65-315(I)-II	50	125	58.84	2960	302	37	50	65	265
86	KQWH65-315(I)A-II	46.7	113	53.94	2960	284	30	50	65	246
87	KQWH65-315(I)B-II	43.3	101	55.04	2960	272	30	50	65	246
88	KQWH65-315(I)C-II	40	85	55.24	2960	252	22	50	65	182
89	KQWH80-100-II	100	12.5	62.75	2960	127	5.5	65	80	55.1
90	KQWH80-100A-II	89	10	65.94	2960	118	4	65	80	48.3
91	KQWH80-125-II	95	20	73.42	2960	146	11	65	80	113
92	KQWH80-125A-II	85	16	79.57	2960	135	7.5	65	80	69.2
93	KQWH80-100(Z)-II	60	16	72.46	2960	123	4	65	80	48.3
94	KQWH80-125(Z)-II	70	26	76.58	2960	148	7.5	65	80	69.2
95	KQWH80-125(Z)A-II	70	20	75.16	2960	137	5.5	65	80	55.1
96	KQWH80-160(Z)-II	75	32	78.95	2960	162	11	65	80	113
97	KQWH80-200(Z)-II	75	50	74.25	2960	194	18.5	65	80	142
98	KQWH80-200(Z)A-II	72	44	74.04	2960	188	15	65	80	123
99	KQWH80-200(Z)B-II	68	38	74.67	2960	183	11	65	80	113
100	KQWH80-160-II	100	32	79.06	2960	168	15	65	80	123
101	KQWH80-160A-II	93.5	28	76.54	2960	160	11	65	80	113
102	KQWH80-160B-II	80	24	73.3	2960	148	11	65	80	113
103	KQWH80-200-II	100	50	76.21	2960	198	22	65	80	182
104	KQWH80-200A-II	93.5	44	77.21	2960	190	18.5	65	80	142
105	KQWH80-250-II	100	80	68.93	2960	255	37	65	80	265
106	KQWH80-250A-II	93.5	70	69.47	2960	240	30	65	80	246
107	KQWH80-250B-II	87	60	68.31	2960	220	30	65	80	246
108	KQWH80-315-II	100	125	64.69	2960	306	75	65	80	546
109	KQWH80-315A-II	95	113	62.1	2960	291	55	65	80	413
110	KQWH80-315B-II	90	101	62.37	2960	269	45	65	80	323
111	KQWH80-315C-II	82	85	65.29	2960	254	37	65	80	265
112	KQWH150-200-II	200	12.5	78.07	1480	229	15	125	150	142
113	KQWH150-200A-II	179	10	82	1480	205	11	125	150	121
114	KQWH150-250-II	200	20	85.53	1480	270	18.5	125	150	181
115	KQWH150-250A-II	180	16	83.89	1480	240	15	125	150	142
116	KQWH150-250B-II	167	14	77.2	1480	228	11	125	150	121
117	KQWH150-315-II	200	32	81.7	1480	322	30	125	150	284
118	KQWH150-315A-II	200	28	74.72	1480	312	22	125	150	209
119	KQWH150-315B-II	173	24	79	1480	291	18.5	125	150	181
120	KQWH150-400-II	200	50	81.23	1480	386	45	125	150	363
121	KQWH150-400A-II	187	44	80.94	1480	363	37	125	150	328
122	KQWH150-400B-II	200	38	82.01	1480	348	30	125	150	284
123	KQWH150-400C-II	160	32	81.52	1480	312	22	125	150	209
124	KQWH150-460-II	200	80	73.82	1480	489	75	125	150	569
125	KQWH150-460A-II	187	70	69.45	1480	456	75	125	150	569
126	KQWH150-460B-II	173	60	68.98	1480	424	55	125	150	442
127	KQWH200-200(Z)-II	300	12.5	79.05	1480	241	18.5	150	200	181
128	KQWH200-200(Z)A-II	280	10	76.32	1480	221.5	15	150	200	142
129	KQWH200-250(Z)-II	300	20	84.01	1480	279	30	150	200	284
130	KQWH200-250(Z)A-II	280	16	82	1480	240	18.5	150	200	181
131	KQWH200-250(Z)B-II	262	13	77	1480	230	15	150	200	142
132	KQWH200-315(Z)-II	300	32	83.52	1480	340	45	150	200	363
133	KQWH200-315(Z)A-II	280	28	79.93	1480	320	37	150	200	328
134	KQWH200-315(Z)B-II	262	24	76.92	1480	300	30	150	200	284
135	KQWH200-400(Z)-II	300	50	79.41	1480	390	75	150	200	569
136	KQWH200-400(Z)A-II	280	44	78.96	1480	370	55	150	200	442
137	KQWH200-400(Z)B-II	260	38	82.12	1480	333	45	150	200	363
138	KQWH200-400(Z)C-II	245	32	79.6	1480	320	37	150	200	328
139	KQWH200-200(I)-II	400	12.5	77.93	1480	251	22	150	200	209
140	KQWH200-200(I)A-II	358	10	76.56	1480	230	18.5	150	200	181
141	KQWH200-250(I)-II	400	20	83.9	1480	282	30	150	200	284
142	KQWH200-250(I)A-II	358	16	81.83	1480	253	22	150	200	209
143	KQWH200-250(I)B-II	322	13	79.38	1480	243	18.5	150	200	181
144	KQWH200-315(I)-II	390	32	83.9	1480	342	55	150	200	442
145	KQWH200-315(I)A-II	360	28	83.8	1480	316	45	150	200	363
146	KQWH200-315(I)B-II	340	24	84.83	1480	295	37	150	200	328
147	KQWH200-400(I)-II	400	50	82.61	1480	390	75	150	200	569
148	KQWH200-400(I)A-II	374	44	81.44	1480	368	75	150	200	569
149	KQWH200-400(I)B-II	370	40	82.04	1480	352	55	150	200	442
150	KQWH200-400(I)C-II	340	36	80.1	1480	340	45	150	200	363
151	KQWH200-460(Z)-II	300	80	71.4	1480	486	110	150	200	939
152	KQWH200-460(Z)A-II	280	70	69	1480	455	90	150	200	639
153	KQWH200-460(Z)B-II	262	60	67.01	1480	433	75	150	200	569
154	KQWH200-460-II	400	80	77.54	1480	492	132	150	200	1033
155	KQWH200-460A-II	374	70	75.5	1480	465	110	150	200	939
156	KQWH200-460B-II	346	60	71.39	1480	436	90	150	200	639
157	KQWH250-250-II	520	20	86.6	1480	292	45	200	250	363
158	KQWH250-250A-II	490	17	84.35	1480	270	37	200	250	328
159	KQWH250-290-II	500	25	78.81	1480	308	45	200	250	363
160	KQWH250-315-II	550	32	78.3	1480	337	75	200	250	569
161	KQWH250-315A-II	500	28	81.87	1480	316	55	200	250	442
162	KQWH250-400-II	500	50	79.8	1480	402	90	200	250	639
163	KQWH250-400A-II	500	44	84.61	1480	389	90	200	250	639
164	KQWH250-400C-II	460	37	83.73	1480	360	75	200	250	569
165	KQWH250-460-II	550	80	81.6	1480	502	200	200	250	1238
166	KQWH250-460A-II	515	70	80	1480	470	160	200	250	1126
167	KQWH250-460B-II	480	60	79	1480	436	132	200	250	1033
168	KQWH250-315(I)-II	720	32	85.4	1480	340	90KW	DN200	DN250	639kg
169	KQWH250-315(I)A-II	630	32	86.16	1480	332	75KW	DN200	DN250	569kg
170	KQWH250-315(I)B-II	700	28	80.21	1480	325	75KW	DN200	DN250	569kg
171	KQWH250-315(I)C-II	600	24	83.47	1480	312	55KW	DN200	DN250	442kg
172	KQWH250-400(I)-II	720	50	85.8	1480	404	132KW	DN200	DN250	1033kg
173	KQWH250-400(I)A-II	660	44	83.34	1480	392	110KW	DN200	DN250	939kg
174	KQWH300-250-E-II	900	20	83.26	1480	299	75	250	300	569
175	KQWH300-250A-E-II	820	18	81.69	1480	281	55	250	300	442
176	KQWH300-250B-E-II	660	18	79.24	1480	274	45	250	300	363
177	KQWH300-315-E-II	900	32	86.3	1480	343.5	110	250	300	939
178	KQWH300-315A-E-II	900	28	84.62	1480	334.5	90	250	300	639
179	KQWH300-400-E-II	900	50	86	1480	420	160	250	300	1126
180	KQWH300-400A-E-II	900	40	84.5	1480	388	132	250	300	1033
181	KQWH300-400B-E-II	800	36	83	1480	366	110	250	300	939
