上海东方泵业DFSS中开双吸泵

DFSS系列双吸泵为卧式单级双吸泵，该系列泵采用水平中开结构形式，并获得国家知识产权局颁发的《实用新型专利证书》和《外观设计专利证书》两项专利，专利证号为 ZL02265708.8 和 ZL02316326.7。同时获得国家科学技术部认定的国家重点新产品和上海市高新技术成果转化认定证书。 DFSS 系列泵具有性能可靠、高效节能、维修方便，使用寿命长等显著特点，自投入市场以来深受用户青睐。产品执行 GB/T5657«离心泵技术条件Ⅲ类»标准。

在线咨询全国热线
4001-077-588

产品概述

工作条件及范围流量范围:66～37000m3/h; 扬程范围：5～180m 进口压力：＜0.3MPa；输送介质温度：常规≤80℃、冷却结构：＜105℃；进口压力≥0.3MPa 或温度≥105℃须特殊订货；

应用范围该系列产品适用于电站、自来水、市政、建筑、消防、工矿企业等行业用于输送清水或物理化学性质类似于清水的其他介质。

上海东方泵业DFSS中开双吸泵参数表

序号	型号	额定流量 m³/h	额定扬程 m	额定转速 rpm	叶轮外径	额定电压 (V)	额定电流 (A)	频率 (Hz)	电机极数	证书
1	DFSS150-13/2	100	36	2960	165	380V	40.5	50Hz	2	CQC12701084503
2		170	28
3		235	19
4	DFSS150-13N/2	85	35	2960	161	380V	27.9	50Hz	2	CQC12701084503
5		145	27
6		200	19
7	DFSS150-4/2	100	122	2960	300	380V	160	50Hz	2	CQC12701084503
8		170	118
9		215	106
10	DFSS150-4N/2	85	117	2960	300	380V	134	50Hz	2	CQC12701084503
11		145	114
12		180	103
13	DFSS150-6/2	100	83	2960	242	380V	99	50Hz	2	CQC12701084503
14		170	78
15		205	70
16	DFSS150-6N/2	85	79	2960	238	380V	80.8	50Hz	2	CQC12701084503
17		145	75
18		175	69
19	DFSS150-7/2	259	140	2960	315	380V	349	50Hz	2	CQC12701084503
20		370	128
21		444	110
22	DFSS150-7N/2	204	120	2960	290	380V	234	50Hz	2	CQC12701084503
23		291	112
24		349	98
25	DFSS150-8/2	100	53	2960	205	380V	67.4	50Hz	2	CQC12701084503
26		170	50
27		220	41
28	DFSS150-8N/2	85	51	2960	199	380V	54.9	50Hz	2	CQC12701084503
29		145	48
30		200	40
31	DFSS150-3E/4	78	85	1480	490	380V	136	50Hz	4
32		130	80
33		156	76
34	DFSS150-3EN/4	68	76	1480	450	380V	103	50Hz	4
35		113	70
36		134	66
37	DFSS200-13/2	175	49	2960	201	380V	80.8	50Hz	2	CQC12701084503
38		290	42
39		355	36
40	DFSS200-13N/2	150	42	2960	189	380V	67.4	50Hz	2	CQC12701084503
41		250	37
42		295	34
43	DFSS200-19/2	175	30	2960	165	380V	54.9	50Hz	2	CQC12701084503
44		290	25
45		355	18
46	DFSS200-19N/2	150	29	2960	161	380V	54.9	50Hz	2	CQC12701084503
47		250	24
48		305	18
49	DFSS200-5/2	175	132	2960	306	380V	280	50Hz	2	CQC12701084503
50		290	126
51		325	120
52	DFSS200-5N/2	150	118	2960	289	380V	234	50Hz	2	CQC12701084503
53		250	112
54		290	106
55	DFSS200-7/2	175	104	2960	270	380V	234	50Hz	2	CQC12701084503
56		290	93
57		340	84
58	DFSS200-7N/2	150	100	2960	264	380V	160	50Hz	2	CQC12701084503
59		250	90
60		290	81
61	DFSS200-9/2	175	72	2960	234	380V	134	50Hz	2	CQC12701084503
62		290	63
63		365	51
64	DFSS200-9N/2	150	68	2960	228	380V	134	50Hz	2	CQC12701084503
65		250	61
66		310	49
67	DFSS200-4/2	168	205	2960	374	380V	436	50Hz	2
68		280	193
69		336	180
70	DFSS200-4N/2	143	196	2960	366	380V	384	50Hz	2	CQC12701084503
71		238	190
72		285	176
73	DFSS250-13/4	300	28	1480	303	380V	84.4	50Hz	4	CQC12701084503
74		500	24
75		600	20
76	DFSS250-13N/4	255	26	1480	295	380V	69.6	50Hz	4	CQC12701084503
77		425	23
78		510	19
79	DFSS250-14/2	330	71	2960	242	380V	234	50Hz	2	CQC12701084503
80		550	60
81		660	50
82	DFSS250-14N/2	290	68	2960	240	380V	195	50Hz	2	CQC12701084503
83		490	60
84		585	51
85	DFSS250-18/4	300	18	1480	254	380V	56.7	50Hz	4	CQC12701084503
86		500	15
87		600	11
88	DFSS250-18N/4	255	17	1480	245	380V	41.8	50Hz	4	CQC12701084503
89		425	14
90		510	11
91	DFSS250-4/4	318	126	1480	594	380V	493	50Hz	4	CQC12701084503
92		530	112
93		636	100
94	DFSS250-4N/4	265	117	1480	598	380V	352	50Hz	4	CQC12701084503
95		440	109
96		530	99
97	DFSS250-6/4	300	80	1480	468	380V	285	50Hz	4	CQC12701084503
98		505	74
99		635	66
100	DFSS250-6N/4	265	79	1480	472	380V	285	50Hz	4	CQC12701084503
101		440	74
102		545	66
103	DFSS250-8/2	330	123	2960	303	380V	384	50Hz	2	CQC12701084503
104		550	109
105		660	93
106	DFSS250-8N/2	295	113	2960	288	380V	323	50Hz	2	CQC12701084503
107		495	98
108		595	83
109	DFSS250-9/4	300	46	1480	367	380V	136	50Hz	4	CQC12701084503
110		500	40
111		600	33
112	DFSS250-9N/4	255	43	1480	356	380V	136	50Hz	4	CQC12701084503
113		425	38
114		510	32
115	DFSS250-5/2	264	232	2960	410	10KV	33	50Hz	2	CQC12701084503
116		440	225
117		528	220
118	DFSS250-5N/2	225	216	2960	394	10KV	25.2	50Hz	2	CQC12701084503
119		375	210
120		450	206
121	DFSS300-13/4	485	39	1480	356	380V	197	50Hz	4	CQC12701084503
122		810	33
123		970	27
124	DFSS300-13N/4	410	37	1480	347	380V	163	50Hz	4	CQC12701084503
125		690	32
126		825	26
127	DFSS300-19/4	485	23	1480	289	380V	103	50Hz	4	CQC12701084503
128		810	19
129		970	13
130	DFSS300-19N/4	410	22	1480	282	380V	84.4	50Hz	4	CQC12701084503
131		685	18.5
132		830	13
133	DFSS300-3/4	474	225	1480	780	10kV	56.1	50Hz	4	CQC12701084503
134		790	220
135		909	215
136	DFSS300-3N/4	402	210	1480	662	10kV	49.2	50Hz	4	CQC12701084503
137		670	206
138		804	202
139	DFSS300-4/4	505	152	1480	685	10kV	35	50Hz	4	CQC12701084503
140		840	149
141		980	141
142	DFSS300-4N/4	425	145	1480	663	10kV	32	50Hz	4	CQC12701084503
143		705	142
144		840	137
145	DFSS300-6/4	485	97	1480	530	380V	554	50Hz	4	CQC12701084503
146		810	93
147		970	85
148	DFSS300-6N/4	410	94	1480	517	380V	440	50Hz	4	CQC12701084503
149		690	90
150		825	82
151	DFSS300-8/4	485	65	1480	443	380V	330	50Hz	4	CQC12701084503
152		810	59
153		995	52
154	DFSS300-8N/4	410	63	1480	434	380V	285	50Hz	4	CQC12701084503
155		690	58
156		845	51
157	DFSS350-13/4	780	53	1480	416	380V	387	50Hz	4	CQC12701084503
158		1300	45
159		1560	37
160	DFSS350-13N/4	660	51	1480	403	380V	330	50Hz	4	CQC12701084503
161		1100	43
162		1320	37
163	DFSS350-19/4	780	34	1480	343	380V	236	50Hz	4	CQC12701084503
164		1300	27
165		1560	21
166	DFSS350-19N/4	660	28	1480	334	380V	163	50Hz	4	CQC12701084503
167		1100	23
168		1320	18
169	DFSS350-26/4	485	18	1480	251	380V	69.6	50Hz	4	CQC12701084503
170		810	13
171		970	9
172	DFSS350-26N/4	410	17	1480	240	380V	69.6	50Hz	4	CQC12701084503
173		690	12
174		825	9
175	DFSS350-27/4	780	20	1480	282	380V	136	50Hz	4	CQC12701084503
176		1300	16
177		1560	12
178	DFSS350-27N/4	660	19	1480	272	380V	136	50Hz	4	CQC12701084503
179		1100	15
180		1320	12
181	DFSS350-6/4	780	135	1480	608	10kV	49.2	50Hz	4	CQC12701084503
182		1300	124
183		1690	104
184	DFSS350-6N/4	660	125	1480	593	10kV	35	50Hz	4	CQC12701084503
185		1100	117
186		1420	92
187	DFSS350-9/4	756	85	1480	506	10kV	25.3	50Hz	4	CQC12701084503
188		1260	76
189		1512	66
190	DFSS350-9N/4	641	80	1480	492	380V	554	50Hz	4	CQC12701084503
191		1069	73
192		1283	66
193	DFSS350-13/6	522	24	990	407	380V	144	50Hz	6	CQC12701084503
194		870	20
195		1044	17
196	DFSS350-4/4	778	234.5	1480	790	10kV	85.3	50Hz	4	CQC12701084503
197		1296	216
198		1490	204.9
199	DFSS350-19/6	522	15	990	345	380V	86	50Hz	6	CQC12701084503
200		870	12
201		1044	9
202	DFSS350-6/6	542	65	990	610	380V	365	50Hz	6	CQC12701084503
203		903	56
204		1084	48
205	DFSS350-9/6	506	38	990	504	380V	207	50Hz	6	CQC12701084503
206		843	34
207		1011	30
208	DFSS350-4N/4	641	218	1480	645	10kV	69.2	50Hz	4	CQC12701084503
209		1069	207
210		1380	183
211	DFSS350-19N/6	441	15	990	328	380V	72	50Hz	6	CQC12701084503
212		736	12
213		883	9
214	DFSS350-13N/6	442	23	990	390	380V	103	50Hz	6	CQC12701084503
215		736	19
216		883	17
217	DFSS350-5/4	623	182.7	1480	702	10kV	56.1	50Hz	4	CQC12701084503
218		1040	162
219		1247	147.6
220	DFSS350-6N/6	441	56	990	590	380V	296	50Hz	6	CQC12701084503
221		736	52
222		950	41
223	DFSS350-9N/6	429	36	990	485	380V	170	50Hz	6	CQC12701084503
224		715	33
225		858	30
226	DFSS350-5N/4	530	176	1480	675	10kV	43.9	50Hz	4	CQC12701084503
227		884	156
228		1060	142
229	DFSS400-13/4	1230	71	1480	478	10kV	32	50Hz	4	CQC12701084503
230		2050	59
231		2540	45
232	DFSS400-13N/4	1055	68	1480	466	10kV	28	50Hz	4	CQC12701084503
233		1765	57
234		2205	45
235	DFSS400-21/4	1230	41	1480	376	380V	387	50Hz	4	CQC12701084503
236		2050	31
237		2560	23
238	DFSS400-21N/4	1055	39	1480	366	380V	352	50Hz	4	CQC12701084503
239		1755	30
240		2200	23
241	DFSS400-24/4	1210	28	1480	342	380V	285	50Hz	4	CQC12701084503
242		1730	25
243		1995	18
244	DFSS400-6/4	1230	169	1480	693	10kV	85.3	50Hz	4	CQC12701084503
245		2050	159
246		2520	150
247	DFSS400-6N/4	1095	158	1480	670	10kV	77.4	50Hz	4	CQC12701084503
248		1825	149
249		2280	133
250	DFSS400-9/4	1345	136	1480	633	10kV	69.2	50Hz	4	CQC12701084503
251		2240	122
252		2685	109
253	DFSS400-9N/4	1110	112	1480	560	10kV	43.9	50Hz	4	CQC12701084503
254		1850	92
255		2315	74
256	DFSS400-5/4	1410	306	1480	912	10kV	170	50Hz	4	CQC12701084503
257		2350	278
258		2938	226
259	DFSS400-5N/4	1212	286	1480	863	10kV	152	50Hz	4	CQC12701084503
260		2020	260
261		2525	211.4
262	DFSS500-13/4	1895	95	1480	566	10kV	63.1	50Hz	4	CQC12701084503
263		3160	84
264		3790	74
265	DFSS500-13N/4	1620	90	1480	551	10kV	56.1	50Hz	4	CQC12701084503
266		2705	81
267		3245	69
268	DFSS500-9/4	1920	158	1480	692	10kV	109	50Hz	4	CQC12701084503
269		3200	143
270		3840	126
271	DFSS500-9N/4	1700	136	1480	645	10kV	85.3	50Hz	4	CQC12701084503
272		2840	122
273		3405	106
274	DFSS500-13/6	1230	45	990	566	10kV	21.5	50Hz	6	CQC12701084503
275		2050	39
276		2460	32
277	DFSS500-13N/6	1040	40	990	551	380V	401	50Hz	6	CQC12701084503
278		1735	35
279		2085	28
280	DFSS500-19/6	1212	28.5	990	459	380V	296	50Hz	6	CQC12701084503
281		2020	23
282		2424	19
283	DFSS500-19N/6	1028	25	990	446	380V	296	50Hz	6	CQC12701084503
284		1714	22
285		2057	18
286	DFSS500-26/6	1230	17	990	386	380V	207	50Hz	6	CQC12701084503
287		2050	14
288		2460	10
289	DFSS500-26N/6	1040	16	990	371	380V	170	50Hz	6	CQC12701084503
290		1735	13
291		2085	10
292	DFSS500-6/6	1230	106	990	802	10kV	57.6	50Hz	6	CQC12701084503
293		2050	98
294		2460	90
295	DFSS500-6N/6	1040	103	990	786	10kV	45.6	50Hz	6	CQC12701084503
296		1740	94
297		2085	87
298	DFSS500-9/6	1230	66	990	692	10kV	33	50Hz	6	CQC12701084503
299		2050	59
300		2460	54
301	DFSS500-9N/6	1040	62	990	645	10kV	26	50Hz	6	CQC12701084503
302		1735	57
303		2015	51
304	DFSS500-17/4	1500	58	1480	430	10kV	32	50Hz	4	CQC12701084503
305		2500	49
306		3000	42
307	DFSS500-7/4	1890	254	1480	854	10kV	188	50Hz	4	CQC12701084503
308		3150	231
309		3938	193
310	DFSS500-12/4	1410	85.9	1480	515	10kV	43.9	50Hz	4	CQC12701084503
311		2350	74
312		2820	62.6
313	DFSS500-12/6	930	38.2	990	515	380V	342	50Hz	6	CQC12701084503
314		1550	33
315		1860	28.3
316	DFSS500-17/6	1005	26	990	430	380V	245	50Hz	6	CQC12701084503
317		1675	22
318		2010	20.2
319	DFSS500-21/6	1258	20	990	424	380V	207	50Hz	6	CQC12701084503
320		1572	18
321		1730	16
322	DFSS500-21/4	1881	45.1	1480	424	380V	554	50Hz	4	CQC12701084503
323		2350	40
324		2587	35.2
325	DFSS500-7N/4	1632	239.8	1480	813	10kV	170	50Hz	4	CQC12701084503
326		2720	218
327		3400	181.7
328	DFSS500-8E/4	1512	172	1480	710	10kV	95.5	50Hz	4
329		2520	155
330		3024	140
331	DFSS500-12N/4	1128	84	1480	488	10kV	35	50Hz	4	CQC12701084503
332		1880	72
333		2256	62
334	DFSS500-12N/6	755	38	990	488	380V	296	50Hz	6	CQC12701084503
335		1258	32
336		1509	28
337	DFSS500-21N/6	803	19	990	398	380V	207	50Hz	6	CQC12701084503
338		1338	17
339		1605	15
340	DFSS500-21N/4	1200	43	1480	398	380V	493	50Hz	4	CQC12701084503
341		2000	38
342		2400	33
343	DFSS500-8EN/4	1342	146	1480	650	10kV	77.4	50Hz	4
344		2236	132
345		2683	116
346	DFSS600-10/6	2800	88	990	785	10kV	87	50Hz	6	CQC12701084503
347		3999	80
348		4598	72
349	DFSS600-18/6	1920	37	990	547	10kV	26	50Hz	6	CQC12701084503
350		3200	32
351		3840	25
352	DFSS600-18N/6	1630	36	990	533	10kV	24	50Hz	6	CQC12701084503
353		2715	31
354		3255	25
355	DFSS600-24/6	1920	27	990	467	10kV	19.3	50Hz	6	CQC12701084503
356		3200	21
357		3840	15
358	DFSS600-24N/6	1630	26	990	452	10kV	17	50Hz	6	CQC12701084503
359		2715	20
360		3260	15
361	DFSS600-6/6	1905	164	990	970	10kV	125	50Hz	6	CQC12701084503
362		3180	144
363		3815	127
364	DFSS600-6N/6	1690	147	990	896	10kV	98	50Hz	6	CQC12701084503
365		2820	123
366		3385	107
367	DFSS600-9/6	1885	93	990	787	10kV	70.9	50Hz	6	CQC12701084503
368		3140	85
369		3610	75
370	DFSS600-9N/6	1540	86	990	757	10kV	51.2	50Hz	6	CQC12701084503
371		2565	80
372		2950	70
373	DFSS600-10N/6	1992	64.4	990	625	10kV	51.2	50Hz	6	CQC12701084503
374		3320	56.5
375		3984	49.1
376	DFSS600-19/6	1230	26	990	480	380V	342	50Hz	6	CQC12701084503
377		2050	23
378		2460	19
379	DFSS600-5/6	2250	182	990	998	10kV	172	50Hz	6	CQC12701084503
380		3750	160
381		4500	142.4
382	DFSS600-11/4	3038	165.5	1480	750	10kV	188	50Hz	4	CQC12701084503
383		5064	149.6
384		6077	131.3
385	DFSS600-10ET/6	2100	65.2	990	625	10kV	57.6	50Hz	6
386		3500	56
387		4200	47.9
388	DFSS600-19N/6	1040	25	990	453	380V	296	50Hz	6	CQC12701084503
389		1740	22
390		2085	18
391	DFSS600-13/6	1620	52.4	990	617	10kV	29	50Hz	6	CQC12701084503
392		2700	45.5
393		3240	37.6
394	DFSS600-5N/6	2154	165	990	964	10kV	156	50Hz	6	CQC12701084503
395		3590	150
396		4487	122
397	DFSS600-10ETN/6	1890	64	990	600	10kV	51.2	50Hz	6
398		3150	55
399		3780	46
400	DFSS600-13/4	2424	122.1	1480	617	10kV	109	50Hz	4	CQC12701084503
401		4040	107
402		4848	89.9
403	DFSS600-11N/4	3132	161.1	1480	735	10kV	170	50Hz	4	CQC12701084503
404		5220	139.7
405		6264	120
406	DFSS600-13N/6	1365	52	990	592	10kV	26	50Hz	6	CQC12701084503
407		2274	45
408		2729	36
409	DFSS600-14/6	1932	59	990	632	10kV	40.4	50Hz	6	CQC12701084503
410		3220	48
411		3864	38
412	DFSS600-13N/4	2040	120	1480	592	10kV	85.3	50Hz	4	CQC12701084503
413		3400	105
414		4080	88
415	DFSS600-16/4	2448	82	1480	515	10kV	69.2	50Hz	4	CQC12701084503
416		3960	70
417		4896	54
418	DFSS600-14/8	1444	33	740	632	10KV	29.2	50Hz	8	CQC12701084503
419		2407	27
420		2888	21
421	DFSS600-16/6	1589	34.8	990	515	10kV	21.5	50Hz	6	CQC12701084503
422		2650	31.7
423		3178	26.5
424	DFSS600-14N/6	1650	58	990	602	10kV	36.2	50Hz	6	CQC12701084503
425		2750	47
426		3300	37
427	DFSS600-16N/4	2040	80	1480	491	10kV	56.1	50Hz	4	CQC12701084503
428		3400	68
429		4080	52
430	DFSS600-19/4	1920	59	1480	480	10kV	40	50Hz	4	CQC12701084503
431		3200	48
432		4000	36
433	DFSS600-14N/8	1233	32	740	602	380V	366	50Hz	8	CQC12701084503
434		2056	26
435		2467	19.5
436	DFSS600-16N/6	1365	36	990	491	10kV	19.3	50Hz	6	CQC12701084503
437		2274	30
438		2729	25
439	DFSS600-8E/8	1920	57	740	858	10kV	43	50Hz	8
440		3200	50
441		3840	43
442	DFSS600-17/6	2160	42.5	990	557	10kV	36.2	50Hz	6	CQC12701084503
443		3600	38.5
444		4320	32
445	DFSS600-19N/4	1630	57	1480	453	10kV	32	50Hz	4	CQC12701084503
446		2715	46
447		3395	35
448	DFSS600-17N/6	1950	54	990	565	10kV	36.2	50Hz	6	CQC12701084503
449		3250	42
450		3900	31
451	DFSS600-20E/8	2242	31	740	624	10kV	28.2	50Hz	8
452		3737	26
453		4500	21
454	DFSS600-8EN/8	1710	55	740	850	10kV	38.5	50Hz	8
455		2850	47
456		3420	45
457	DFSS600-20EN/8	1875	31	740	600	10kV	22.7	50Hz	8
458		3124	25
459		3749	20
460	DFSS700-12/6	4685	96	990	839	10kV	139	50Hz	6	CQC12701084503
461		6695	85
462		8035	75
463	DFSS700-12N/6	3635	82	990	650	10kV	98	50Hz	6	CQC12701084503
464		5190	73
465		6230	66
466	DFSS700-13/6	3355	78	990	750	10kV	79.2	50Hz	6	CQC12701084503
467		4795	68
468		5755	59
469	DFSS700-13N/6	2710	73	990	720	10kV	63.9	50Hz	6	CQC12701084503
470		3870	64
471		4645	57
472	DFSS700-15/6	2400	59.2	990	622	10kV	51.2	50Hz	6	CQC12701084503
473		4000	50
474		4800	41.9
475	DFSS700-15N/6	2190	58	990	600	10kV	45.6	50Hz	6	CQC12701084503
476		3650	49
477		4380	40
478	DFSS700-25/6	3190	31	990	513	10kV	29	50Hz	6	CQC12701084503
479		4560	25
480		5470	18
481	DFSS700-25N/6	2475	28	990	487	10KV	24	50Hz	6	CQC12701084503
482		3540	23
483		4250	18
484	DFSS700-20/8	2555	26	740	598	10kV	22.7	50Hz	8	CQC12701084503
485		3650	20.5
486		4380	16
487	DFSS700-25/8	2385	18	740	513	380V	366	50Hz	8	CQC12701084503
488		3410	14
489		4090	11
490	DFSS700-25N/8	1850	15	740	487	380V	260	50Hz	8	CQC12701084503
491		2645	13
492		3175	10
493	DFSS700-27/8	3620	21	740	586	10kV	28.2	50Hz	8	CQC12701084503
494		5170	18
495		6205	15
496	DFSS700-27N/8	2870	19	740	563	10kV	20.3	50Hz	8	CQC12701084503
497		4100	17
498		4920	14
499	DFSS700-12ET/6	3300	87.1	990	778	10kV	98	50Hz	6
500		5500	76
501		6600	65.2
502	DFSS700-14/6	1740	59	990	632	10kV	36.2	50Hz	6	CQC12701084503
503		2900	50
504		3480	42
505	DFSS700-22/6	2100	34	990	546	10kV	26	50Hz	6	CQC12701084503
506		3500	29
507		4200	24
508	DFSS700-7/6	3150	184.6	990	1060	10kV	193	50Hz	6	CQC12701084503
509		5250	160
510		6300	138
511	DFSS700-22/8	1570	19	740	546	380V	314.4	50Hz	8	CQC12701084503
512		2616	16
513		3139	13
514	DFSS700-7/8	2355	111	740	1060	10kV	101	50Hz	8	CQC12701084503
515		3924	100
516		4709	90
517	DFSS700-12ETN/6	2820	86	990	700	10kV	87	50Hz	6
518		4700	75
519		5640	64
520	DFSS700-14N/6	1470	59	990	610	10kV	33	50Hz	6	CQC12701084503
521		2450	50
522		2940	42
523	DFSS700-16/6	2160	42.5	990	566	10kV	36.2	50Hz	6	CQC12701084503
524		3600	38.5
525		4320	32
526	DFSS700-22N/6	1830	33	990	522	10KV	24	50Hz	6	CQC12701084503
527		3050	28
528		3660	23
529	DFSS700-8/6	3042	127	990	923	10kV	139	50Hz	6	CQC12701084503
530		5070	116
531		6084	93
532	DFSS700-7N/6	2628	173	990	1008	10kV	172	50Hz	6	CQC12701084503
533		4380	154
534		5475	126
535	DFSS700-22N/8	1350	18	740	522	380V	260	50Hz	8	CQC12701084503
536		2250	15
537		2700	12
538	DFSS700-8N/6	2610	114	990	854	10kV	111	50Hz	6	CQC12701084503
539		4350	104
540		5220	94
541	DFSS700-7ET/10	1878	66	590	1060	10kV	49.1	50Hz	10	CQC12701084503
542		3129	57
543		3755	50
544	DFSS700-7N/8	1964	107	740	1008	10kV	90	50Hz	8	CQC12701084503
545		3274	97
546		3929	86
547	DFSS700-7ET/8	2355	103	740	1060	10kV	90	50Hz	8
548		3924	89
549		4709	77
550	DFSS700-8/8	2274	71	740	923	10kV	66.1	50Hz	8	CQC12701084503
551		3790	65
552		4548	59
553	DFSS700-16N/6	1950	54	990	574	10kV	36.2	50Hz	6	CQC12701084503
554		3250	42
555		3900	31
556	DFSS700-17/6	3000	56	990	662	10kV	57.6	50Hz	6	CQC12701084503
557		5000	46
558		6000	36
559	DFSS700-7ETN/10	1721	68	590	1008	10kV	49.1	50Hz	10	CQC12701084503
560		2869	60
561		3586	51
562	DFSS700-7ETN/8	1964	97	740	1008	10kV	73	50Hz	8
563		3274	86
564		4092	70
565	DFSS700-8N/8	2156	62	740	854	10kV	52.3	50Hz	8	CQC12701084503
566		3080	56
567		3696	51
568	DFSS700-12/8	3502	54	740	839	10kV	66.1	50Hz	8	CQC12701084503
569		5004	47
570		6006	42
571	DFSS700-17N/6	2508	55	990	626	10kV	45.6	50Hz	6	CQC12701084503
572		4180	45
573		5016	35
574	DFSS700-11/6	3060	70	990	726	10kV	70.9	50Hz	6	CQC12701084503
575		5100	57
576		6120	49
577	DFSS700-12N/8	2717	46	740	650	10kV	46.4	50Hz	8	CQC12701084503
578		3879	41
579		4657	37
580	DFSS700-11N/6	2448	71	990	692	10kV	57.6	50Hz	6	CQC12701084503
581		4080	57
582		4896	47
583	DFSS700-11/8	2288	40	740	726	10kV	35.2	50Hz	8	CQC12701084503
584		3813	32
585		4575	28
586	DFSS700-11N/8	1830	40	740	692	10kV	28.2	50Hz	8	CQC12701084503
587		3050	32
588		3660	27
589	DFSS700-13/8	2508	44	740	731	10kV	38.5	50Hz	8	CQC12701084503
590		3584	38
591		4302	34
592	DFSS700-14/8	1290	32.5	740	632	10KV	29.2	50Hz	8	CQC12701084503
593		2150	29
594		2580	25.2
595	DFSS700-13N/8	2026	41	740	687	10kV	31.3	50Hz	8	CQC12701084503
596		2893	36
597		3472	32
598	DFSS700-14N/8	1098	31.5	740	610	380V	366	50Hz	8	CQC12701084503
599		1830	28
600		2196	24.2
601	DFSS700-17/8	2242	31	740	662	10kV	28.2	50Hz	8	CQC12701084503
602		3737	26
603		4485	20
604	DFSS700-17N/8	1875	31	740	626	10kV	22.7	50Hz	8	CQC12701084503
605		3124	25
606		3749	20
607	DFSS800-12/6	4685	96	990	839	10kV	139	50Hz	6	CQC12701084503
608		6695	85
609		8035	75
610	DFSS800-12N/6	3635	82	990	776	10kV	98	50Hz	6	CQC12701084503
611		5190	73
612		6230	66
613	DFSS800-13/6	3355	78	990	750	10kV	87	50Hz	6	CQC12701084503
614		4795	68
615		5755	60
616	DFSS800-13N/6	2710	73	990	720	10kV	63.9	50Hz	6	CQC12701084503
617		3870	64
618		4645	57
619	DFSS800-17/6	3360	71	990	622	10kV	87	50Hz	6	CQC12701084503
620		5600	60
621		6720	49
622	DFSS800-18/6	4825	55	990	679	10kV	79.2	50Hz	6	CQC12701084503
623		6890	48
624		8270	38
625	DFSS800-22/6	4030	41	990	594	10kV	51.2	50Hz	6	CQC12701084503
626		5760	35
627		6910	30
628	DFSS800-18N/6	3890	54	990	672	10kV	70.9	50Hz	6	CQC12701084503
629		5560	49
630		6670	42
631	DFSS800-17N/6	2880	70	990	600	10kV	79.2	50Hz	6	CQC12701084503
632		4800	59
633		5760	48
634	DFSS800-22N/6	3240	39	990	577	10kV	40.4	50Hz	6	CQC12701084503
635		4630	34
636		5555	29
637	DFSS800-9/6	4330	142	990	969	10kV	193	50Hz	6	CQC12701084503
638		6185	127
639		7420	116
640	DFSS800-9N/6	3535	133	990	935	10kV	156	50Hz	6	CQC12701084503
641		5050	121
642		6060	112
643	DFSS800-10/8	4620	97	740	1085	10kV	160	50Hz	8	CQC12701084503
644		6600	88
645		7920	80
646	DFSS800-10N/8	3585	82	740	995	10kV	101	50Hz	8	CQC12701084503
647		5120	74
648		6145	68
649	DFSS800-14/8	4780	60	740	893	10kV	90	50Hz	8	CQC12701084503
650		6830	52
651		8195	46
652	DFSS800-14N/8	3710	58	740	862	10kV	73	50Hz	8	CQC12701084503
653		5300	50
654		6360	46
655	DFSS800-18/8	3605	31	740	679	10kV	38.5	50Hz	8	CQC12701084503
656		5150	27
657		6180	22
658	DFSS800-18N/8	2795	30	740	672	10kV	31.3	50Hz	8	CQC12701084503
659		3990	26
660		4790	22
661	DFSS800-15/6	3300	87.1	990	772	10kV	98	50Hz	6	CQC12701084503
662		5500	76
663		6600	65.2
664	DFSS800-16/6	3420	57.2	990	690	10kV	70.9	50Hz	6	CQC12701084503
665		5700	50
666		6840	41.6
667	DFSS800-19/6	4000	43.5	990	614	10kV	51.2	50Hz	6	CQC12701084503
668		5000	39
669		5500	34.3
670	DFSS800-26/6	3888	37.5	990	575	10kV	51.2	50Hz	6	CQC12701084503
671		6480	30
672		7776	24.5
673	DFSS800-11/8	4500	83	740	950	10kV	129	50Hz	8	CQC12701084503
674		7500	70
675		9000	55
676	DFSS800-19/8	3160	24.3	740	614	10kV	25.2	50Hz	8	CQC12701084503
677		3950	21.7
678		4345	20
679	DFSS800-15/8	2400	49.8	740	772	10kV	46.4	50Hz	8	CQC12701084503
680		4000	44
681		4800	38.6
682	DFSS800-16/8	2580	32.3	740	690	10kV	35.2	50Hz	8	CQC12701084503
683		4300	28.3
684		5160	23.6
685	DFSS800-15N/6	2820	86	990	745	10kV	87	50Hz	6	CQC12701084503
686		4700	75
687		5640	64
688	DFSS800-16N/6	3000	56	990	665	10kV	63.9	50Hz	6	CQC12701084503
689		5000	49
690		6000	41
691	DFSS800-19N/6	2580	42.5	990	584	10kV	45.6	50Hz	6	CQC12701084503
692		4300	38
693		5160	33
694	DFSS800-26N/6	2981	33	990	492	10kV	40.4	50Hz	6	CQC12701084503
695		4968	23.7
696		5962	16
697	DFSS800-11N/8	3780	79	740	894	10kV	116	50Hz	8	CQC12701084503
698		6300	67
699		7560	54
700	DFSS800-12/8	3502	54	740	825	10kV	66.1	50Hz	8	CQC12701084503
701		5004	47
702		6006	42
703	DFSS800-16N/8	2242	31	740	657	10kV	31.3	50Hz	8	CQC12701084503
704		3737	27
705		4485	23
706	DFSS800-19N/8	1928	24	740	579	10kV	20.3	50Hz	8	CQC12701084503
707		3214	21
708		3857	18
709	DFSS800-15N/8	2108	48	740	740	10kV	43	50Hz	8	CQC12701084503
710		3513	42
711		4216	36
712	DFSS800-24/8	4199	30.5	740	675	10kV	46.4	50Hz	8	CQC12701084503
713		6999	24
714		8399	18.3
715	DFSS800-12N/8	2717	46	740	744	10kV	46.4	50Hz	8	CQC12701084503
716		3879	41
717		4657	37
718	DFSS800-24N/8	3575	29.8	740	632	10kV	38.5	50Hz	8	CQC12701084503
719		5958	22.8
720		7150	17.5
721	DFSS900-10/8	6980	111	740	1169	10kV	419.9	50Hz	8	CQC12701084503
722		9970	98
723		11965	89
724	DFSS900-10N/8	5410	94	740	1080	10kV	296.4	50Hz	8	CQC12701084503
725		7730	84
726		9275	76
727	DFSS900-13/8	6930	80	740	1027	10kV	296.4	50Hz	8	CQC12701084503
728		9900	69.5
729		11880	61.5
730	DFSS900-13N/8	5370	68	740	952	10kV	116	50Hz	8	CQC12701084503
731		7670	60
732		9200	54
733	DFSS900-17/8	6760	56	740	906	10kV	116	50Hz	8	CQC12701084503
734		9660	50
735		11590	41
736	DFSS900-17N/8	5245	48	740	838	10kV	90	50Hz	8	CQC12701084503
737		7490	43
738		8990	39
739	DFSS900-24/8	6370	37	740	744	10kV	66.1	50Hz	8	CQC12701084503
740		9100	30
741		10920	25
742	DFSS900-24N/8	4940	32	740	691	10kV	46.4	50Hz	8	CQC12701084503
743		7060	26
744		8470	22
745	DFSS900-24/10	5035	24	590	744	10kV	36.2	50Hz	10	CQC12701084503
746		7195	19
747		8635	15
748	DFSS900-24N/10	3905	22	590	691	10kV	29	50Hz	10	CQC12701084503
749		5580	17
750		6695	15
751	DFSS900-12/6	4800	109.4	990	866	10kV	172	50Hz	6	CQC12701084503
752		8000	93
753		9600	77
754	DFSS900-12/8	3600	66	740	866	10kV	81	50Hz	8	CQC12701084503
755		6000	53
756		7200	47
757	DFSS900-16/8	3465	32	740	706	10kV	43	50Hz	8	CQC12701084503
758		5776	27
759		6931	21
760	DFSS900-18/8	3677	44	740	780	10kV	58.9	50Hz	8	CQC12701084503
761		6200	36
762		7355	28
763	DFSS900-17/10	5344	35	590	884	10kV	68	50Hz	10	CQC12701084503
764		7637	31
765		9162	28
766	DFSS900-23/10	4743	32	590	850	10kV	55.3	50Hz	10	CQC12701084503
767		7905	25
768		9486	22
769	DFSS900-12N/6	4200	108	990	836	10kV	156	50Hz	6	CQC12701084503
770		7000	92
771		8400	76
772	DFSS900-16/6	4636	60	990	706	10kV	98	50Hz	6	CQC12701084503
773		7727	48
774		9272	43
775	DFSS900-12N/8	3139	60	740	828	10kV	73	50Hz	8	CQC12701084503
776		5232	51
777		6279	42
778	DFSS900-16N/8	2982	33	740	669	10kV	38.5	50Hz	8	CQC12701084503
779		4971	26
780		5965	23
781	DFSS900-23/8	6000	52	740	850	10kV	101	50Hz	8	CQC12701084503
782		10000	40
783		12000	36
784	DFSS900-18N/8	2601	43	740	727	10kV	46.4	50Hz	8	CQC12701084503
785		4672	36
786		5202	27
787	DFSS900-17N/10	4146	30	590	800	10kV	49.1	50Hz	10	CQC12701084503
788		5921	27
789		7107	24
790	DFSS900-13/10	5525	52	590	1027	10kV	94	50Hz	10	CQC12701084503
791		7893	44
792		9471	37
793	DFSS900-23N/10	4032	31	590	820	10kV	49.1	50Hz	10	CQC12701084503
794		6720	25
795		8064	21
796	DFSS900-18/6	4920	78	990	780	10kV	125	50Hz	6	CQC12701084503
797		8200	64
798		9840	50
799	DFSS900-16N/6	3990	59	990	679	10kV	87	50Hz	6	CQC12701084503
800		6650	47
801		7980	42
802	DFSS900-23N/8	5100	50	740	820	10kV	90	50Hz	8	CQC12701084503
803		8500	40
804		10200	34
805	DFSS900-13N/10	4281	43	590	952	10kV	68	50Hz	10	CQC12701084503
806		6115	38
807		7338	34
808	DFSS900-18N/6	3750	78	990	731	10kV	98	50Hz	6	CQC12701084503
809		6250	64
810		7500	50
811	DFSS1000-12/8	5610	87	740	1122	10kV	160	50Hz	8	CQC12701084503
812		9350	75
813		11220	62
814	DFSS1000-14/12	6777	47	490	1433	10kV	214.6	50Hz	12	CQC12701084503
815		11295	39
816		14119	30
817	DFSS1000-12N/8	4860	86	740	1075	10kV	143	50Hz	8	CQC12701084503
818		8100	73
819		9720	60
820	DFSS1000-15/8	7976	86	740	1248	10kV	419.9	50Hz	8	CQC12701084503
821		13292	74
822		15950	61
823	DFSS1000-12/10	4500	55	590	1122	10kV	94	50Hz	10	CQC12701084503
824		7500	49
825		9000	43
826	DFSS1000-14N/12	5681	45	490	1346	10kV	101	50Hz	12	CQC12701084503
827		9468	37
828		11835	28
829	DFSS1000-22/12	8260	26	490	973	10kV	82	50Hz	12	CQC12701084503
830		11800	22.5
831		14160	19.5
832	DFSS1000-20/8	7250	52	740	900	10kV	129	50Hz	8	CQC12701084503
833		12083	43
834		14500	35
835	DFSS1000-15N/8	7045	83	740	1193	10kV	331.6	50Hz	8	CQC12701084503
836		11742	71
837		14090	58
838	DFSS1000-12N/10	3875	55	590	1074	10kV	84	50Hz	10	CQC12701084503
839		6458	47
840		7750	39
841	DFSS1000-14/10	8160	69	590	1433	10kV	304.4	50Hz	10	CQC12701084503
842		13600	57
843		17000	44
844	DFSS1000-22N/12	6856	24	490	875	10kV	52	50Hz	12	CQC12701084503
845		9794	19
846		11753	14.8
847	DFSS1100-29/12	6960	20.3	490	874	10kV	52	50Hz	12	CQC12701084503
848		11600	15
849		13920	12
850	DFSS1000-24/12	5770	20.7	490	860	10kV	52	50Hz	12	CQC12701084503
851		9617	16.6
852		11541	13.8
853	DFSS1000-20N/8	6180	51	740	857	10kV	116	50Hz	8	CQC12701084503
854		10300	42
855		12360	34
856	DFSS1000-20/10	5780	33	590	900	10kV	68	50Hz	10	CQC12701084503
857		9634	27
858		11561	22
859	DFSS1000-14N/10	6840	65	590	1345	10kV	273.1	50Hz	10	CQC12701084503
860		11400	54
861		14250	42
862	DFSS1000-24N/12	4574	20	490	744	10kV	33.6	50Hz	12	CQC12701084503
863		7624	13.2
864		9149	10.6
865	DFSS1000-22/10	9800	38	590	973	10kV	119	50Hz	10	CQC12701084503
866		14000	32
867		16800	25
868	DFSS1000-24/10	6948	30	590	860	10kV	75	50Hz	10	CQC12701084503
869		11580	24
870		13896	20
871	DFSS1000-20N/10	5010	32	590	855	10kV	62	50Hz	10	CQC12701084503
872		8350	26
873		10020	21
874	DFSS1000-22N/10	8134	34	590	869	10kV	75	50Hz	10	CQC12701084503
875		11620	27
876		13944	19
877	DFSS1100-29/10	8352	27	590	874	10kV	84	50Hz	10	CQC12701084503
878		13920	22
879		16704	19
880	DFSS1000-24N/10	5508	29	590	745	10kV	49.1	50Hz	10	CQC12701084503
881		9180	19.1
882		11016	15.3
883	DFSS1200-13/10	9940	72	590	1227	10kV	378.2	50Hz	10	CQC12701084503
884		14200	63
885		15905	56
886	DFSS1200-18/10	9650	47	590	1042	10kV	134	50Hz	10	CQC12701084503
887		13790	41
888		16545	35
889	DFSS1200-20/12	12165	39	490	1135	10kV	228.9	50Hz	12	CQC12701084503
890		17380	33
891		20855	27
892	DFSS1200-26/12	11215	28	490	968	10kV	101	50Hz	12	CQC12701084503
893		16020	22
894		19220	17
895	DFSS1200-26/16	8410	16	372	968	10kV	45	50Hz	16	CQC12701084503
896		12015	12
897		14415	9
898	DFSS1200-13N/10	7739	77	590	1057	10kV	340.6	50Hz	10	CQC12701084503
899		12898	62
900		15477	51
901	DFSS1200-13ET/10	8400	62	590	1124	10kV	304.4	50Hz	10
902		14000	52
903		16800	44
904	DFSS1200-12/10	6240	66.2	590	1148	10kV	244.1	50Hz	10	CQC12701084503
905		10400	57
906		12480	47.9
907	DFSS1200-18N/10	6900	42	590	931	10kV	106	50Hz	10	CQC12701084503
908		11500	35
909		13800	30.1
910	DFSS1200-18/12	8083	33	490	1030	10kV	90	50Hz	12	CQC12701084503
911		11551	28
912		13858	24
913	DFSS1200-17/10	6841	46	590	1050	10kV	119	50Hz	10	CQC12701084503
914		11401	39
915		14252	34
916	DFSS1200-20/16	9235	22	372	1144	10kV	76	50Hz	16	CQC12701084503
917		13195	19
918		15833	16
919	DFSS1300-17/12	10110	52	490	1184	10kV	349.8	50Hz	12
920		16850	43.7
921		20220	38
922	DFSS1200-20/14	10551	29	425	1144	10kV	168	50Hz	14	CQC12701084503
923		15074	25
924		18089	20
925	DFSS1200-21/10	11250	34.9	590	970	10kV	106	50Hz	10	CQC12701084503
926		12500	32.3
927		14375	27.4
928	DFSS1200-21/12	6300	36.4	490	970	10kV	90	50Hz	12	CQC12701084503
929		10500	29.2
930		12600	23.6
931	DFSS1200-26N/16	6199	16	372	898	10kV	37	50Hz	16	CQC12701084503
932		10331	11
933		12397	8
934	DFSS1200-13/12	8326	51	490	1238	10kV	228.9	50Hz	12	CQC12701084503
935		11894	44
936		13322	39
937	DFSS1200-26N/12	8165	28.2	490	898	10kV	74	50Hz	12	CQC12701084503
938		13608	19.3
939		16330	14.5
940	DFSS1200-12N/10	4712	65	590	1090	10kV	119	50Hz	10	CQC12701084503
941		7853	57
942		9424	48
943	DFSS1200-13ETN/10	7740	57	590	1000	10kV	273.1	50Hz	10
944		12900	48
945		15480	42
946	DFSS1200-17N/10	5815	46	590	1020	10kV	106	50Hz	10	CQC12701084503
947		9691	39
948		11629	33
949	DFSS1200-18N/12	5779	29	490	931	10kV	65	50Hz	12	CQC12701084503
950		9632	24
951		11559	21
952	DFSS1200-21N/10	6458	35	590	929	10kV	94	50Hz	10	CQC12701084503
953		10764	32
954		13024	26
955	DFSS1200-13N/12	6482	54	490	1196	10kV	214.6	50Hz	12	CQC12701084503
956		10803	43
957		12964	36
958	DFSS1200-20N/14	7188	26	425	998	10kV	73	50Hz	14	CQC12701084503
959		11112	21
960		14375	18
961	DFSS1300-17N/12	9099	51	490	1000	10kV	312.6	50Hz	12
962		15165	42
963		18198	37
964	DFSS1200-21N/12	9270	24.2	490	883	10kV	65	50Hz	12	CQC12701084503
965		10300	22.5
966		11845	19.2
967	DFSS1200-20N/16	6291	20	372	1003	10kV	57	50Hz	16	CQC12701084503
968		9727	16
969		12583	14
970	DFSS1200-20N/12	8287	34	490	1001	10kV	113	50Hz	12	CQC12701084503
971		13812	28
972		16574	24
973	DFSS1200-12/8	7800	104.2	740	1148	10kV	467.2	50Hz	8	CQC12701084503
974		13000	90
975		15600	75.9
976	DFSS1200-12N/8	5910	103	740	1086	10kV	373	50Hz	8	CQC12701084503
977		9850	89
978		11820	75
979	DFSS1200-17/8	8580	73	740	1050	10kV	373	50Hz	8	CQC12701084503
980		14300	62
981		17875	53
982	DFSS1200-17N/8	7293	72	740	1012	10kV	331.6	50Hz	8	CQC12701084503
983		12155	61
984		14586	52
985	DFSS1200-21/8	14040	55.9	740	970	10kV	331.6	50Hz	8	CQC12701084503
986		15600	52
987		18720	41.6
988	DFSS1200-21N/8	8100	55	740	928	10kV	296.4	50Hz	8	CQC12701084503
989		13500	51
990		16335	41
991	DFSS1400-27/16	12311	24.2	372	1129	10kV	173.7	50Hz	16	CQC12701084503
992		20520	17
993		24622	11.7
994	DFSS1400-29/18	10800	16	331	1110	10kV	70.3	50Hz	18	CQC12701084503
995		18000	10
996		21600	6.6
997	DFSS1400-27N/16	10464	23	372	1054	10kV	139.2	50Hz	16	CQC12701084503
998		17440	15.8
999		20928	10.2
1000	DFSS1400-27/12	13777	32.9	490	1120	10kV	284.2	50Hz	12	CQC12701084503
1001		22962	27.4
1002		27554	22.5
1003	DFSS1400-27/14	13356	27.8	425	1120	10kV	214.6	50Hz	14	CQC12701084503
1004		22260	19
1005		26712	12
1006	DFSS1400-27N/12	12326	31.4	490	1054	10kV	228.9	50Hz	12	CQC12701084503
1007		20544	25.9
1008		24653	21
1009	DFSS1400-14/12	12000	73	490	1435	10kV	559.2	50Hz	12	CQC12701084503
1010		20000	60
1011		24000	52
1012	DFSS1400-27N/14	11950	29.9	425	1054	10kV	188	50Hz	14	CQC12701084503
1013		19916	20.6
1014		23899	13.2
1015	DFSS1400-14N/12	10800	71	490	1300	10kV	498.6	50Hz	12	CQC12701084503
1016		18000	58
1017		21600	50
1018	DFSS1400-12/8	12258	125	740	1290	10kV	824.1	50Hz	8	CQC12701084503
1019		16452	113
1020		18900	99
1021	DFSS1400-12N/8	10419	119	740	1220	10kV	652.7	50Hz	8	CQC12701084503
1022		13984	107
1023		16065	94
1024	DFSS1600-26/16	17515	26	372	1242	10kV	218.8	50Hz	16	CQC12701084503
1025		25020	21
1026		30020	16
1027	DFSS1600-26/20	14010	17	298	1242	10kV	136.8	50Hz	20	CQC12701084503
1028		20015	13
1029		24015	10
1030	DFSS1600-26N/16	12759	25.7	372	1138	10kV	173.7	50Hz	16	CQC12701084503
1031		21265	18.5
1032		25518	14.5
1033	DFSS1600-26N/20	10207	16.4	298	1138	10kV	108.1	50Hz	20	CQC12701084503
1034		17012	11.8
1035		19863	9.4

上海东方泵业DFSS中开双吸泵

相关产品 / service
